The Galleon NTS-6001-GPS NTP Server combines a GPS receiver with an embedded solid state computer running the Linux operating system.
The unit connects directly to the network via a CAT5 Ethernet connection and fits in a standard 19" rack. This NTP server incorporates a GPS computer clock and a highly accurate remote antenna that tracks up to 12 satellites for increased precision. The antenna is fully weather proof (IP65) as it must be installed externally, preferably on a roof top with a 360 ° view of the sky, it can be positioned up to 200m (600 ft) away as standard, or up to 1,000m (3,000ft) using an optional antenna extension kit.
The NTS-6001-GPS has a backlit LCD display to show run-time information for both the GPS subsystem and the NTP server and to aid installation. The Software drivers conform to the Network Time Protocol Version 4 (NTP V4) and are available for uni-cast, broadcast or multi-cast NTP time synchronization.
Key features
- Ready-to-operate Secure Stratum 1 NTP Time Server
- Includes GPS active antenna + can support a secondary time receiver for the MSF radio signal
- Support for NTP v2, NTP v3, NTP v4 and SNTP compatible clients
- Configured across network via a secure browser interface by http / html / https (RFC2616)
- Dual RJ-45 Ethernet interfaces 10/100 MBit
- Can handle more than 10,000 NTP requests per minute per port, ideal for large networks
- MD5 authentication for advanced security
- Able to Peer with other NTP time servers for enhanced synchronization security
- Solid State Flash memory enables software upgrades and eliminates 'disk failure'
- Front Panel display for Time and Satellite and Radio time Status
- SNTP and NTP protocol support
- Syslog error reporting
Our customers
At Galleon we are proud of our products, please find below a small selection of our customers who have bought Galleon time synchronisation products for there computer networks.
Galleon Compliance
All Galleon Time servers are compliant to the following standards
